Battery Electrode Calendering Equipment with Heating for Lab Battery Research
Brief Introduction
STC-DRG-100 is a compact electric hot battery electrode calendering equipment,whose max temp can reach 120℃ adjustable with digital display. The standard roller is 100mm width, others width roller is optional.
Features
● High roller hardness HRC62, surface plated by chrome treatment.
● Heating temperature max up to 120℃, digital display by thermostat.
● Safety protection cover is designed to prevent hand injured from high temperature.
● Pressing thickness can be adjusted.
● Rolling speed can be adjusted by speed controller.
● Forward & backward are available.
Technical Parameters
|
Model
|
STC-DRG-100
|
|
Working voltage
|
AC110
|
|
Roller
|
Dia.100 x W100mm (other width can be optional )
|
|
Roller hardness
|
>HRC62
|
|
Pressing thickness
|
0~2mm adjustable
|
|
Feeding speed
|
Max 10mm/s adjustable
|
|
Heating temperature
|
Room temperature to 120℃ adjustable, digital display
|
|
Power
|
720W
|
|
Dimension
|
L380 * W280 * H366mm
|
|
Weight
|
57kg
|
Warranty
1 year's warranty with lifetime support.
FAQ
1. Are you a manufacturer ?
A: Yes, our factory is located in Shenzhen, China,
We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R&D department.
2. Do you accept customized product ?
A : Yes. Most of our products can be customzied to meet different requirements.
3. Will you provide test video before dispatch?
A : Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service ?
A : Yes, we can dispatch professional engineer for on-site installation service.
