300mm Roller Battery Calendering Machine Hot Hydraulic Calender

Brand Name : TICO

Model Number : STC-DYG-300S

Place of Origin : Shenzhen, China

MOQ : 1 Set

Price : Negotiable

Payment Terms : T/T

Supply Ability : 10 sets per month

Delivery Time : 12~17 working days

Packaging Details : Standard export wooden box package

Product Name : Hot Hydraulic Calender

Pressing Pressure : Customizable

Pressing Speed : Max 6m/min

Roller diameter : φ200mm

Roller Width : 300mm

Heating temperature : RT~130℃ adjustable

Contact Now

330mm Roller Battery Calendering Machine Hot Hydraulic Calender



Hot Hydraulic Calender with Winder &Unwinder for Lithium Battery Cathode &Anode Material



Brief Introduction for Hot Hydraulic Calender



STC-DYG-300S is a hot hydraulic rolling press machine, which is used for battery electrode rolling press process. Winding&unwinding device is optional.



Technical Parameters for Hot Hydraulic Roll Press Machine


 Model

 STC-DYG-300S

 Power

 AC220V
 Heating temperature  RT~130℃ adjustable

 Pressing speed

 Max 6m/min

 Roller diameter

 φ330mm

 Roller material

 9Cr3Mo

 Roller surface hardness

 ＞HRC65

 Roller width

 330mm

 Pressing thickness

 Max 2mm

 Pressing accuracy

 ±1.5μm

 Power

 3KW

 Installation size

 L2500 x W1500 x H1300mm

 ( Roll press machine + winding & unwinding device )

 Compressed air

 0.5~0.8Mpa

 Weight

 ≈ 600kg



Features



• The pressing thickness is adjustable.

• It is designed with tension control.

• Winding&unwinding device with correction function.

• Touch screen control, high automation.

• RT~130℃ heating temperature adjustable.



Warranty



1 year's warranty with lifetime support.



FAQ



1. Are you a manufacturer ?



A: Yes, our factory is located in Shenzhen, China . We have more than 10 years experience for manufacturing battery lab research equipment .
We owns a professional R&D department.



2. Do you accept customized product ?

A : Yes. Most of our products can be customzied to meet different requirements.



3. Will you provide test video before dispatch?

A : Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service ?

A : Yes, we can dispatch professional engineer for on-site installation service.
